Item# 1839

The M2 Organic LED Digital Monitor measures essential electrical system parameters with adjustable alarms and an auto-dimming display.

The M2 Monitors include a MOSFET External Circuit Relay (ECR) which can be used to control external circuits based on any value measured by the M2.

Features:

• Auto-dimming, bright Organic LED display is easy to read
• 80dB alarm on all models
• Isolated 500mA MOSFET relay
• Intuitive tank level monitoring
• Monitor up to 4 tanks
• Auto calibration for unique tank shapes
• Compatible with common sending units

Specifications:

• Meter:Tank
• Function:Monitors tank volume in up to 4 tanks
• Resolution:1%
• Alarm/Relay Activation:High and Low Level
• Display Size:55mm x 28mm
• Input Voltage:7-70V DC
• Range:0.3W-1.0W
• Tank Alarms:80dB
• Tank Shapes:Custom shapes, auto calibration
• Weight:4.00lb (1.81 kg)
